Inflatable Element (Slat Type)

رسانه جدید

The slat-reinforced inflatable element includes a plurality of longitudinal metal ribs which are partially overlapping to allow expansion of the element while providing a barrier against extrusion. The slat type construction is recommended for single set operations where the tool is released from the running string and must be capable of staying in position without sliding.



Advantages:

• Single-set applications

• Cased hole

• Up to 3:1 expansion ratio

• High temperature capability

• Exposed slats function as slips





INFLATABLE ELEMENT (SLAT TYPE) RATING PRESSURE

Standard Services

Element OD [inch]

ID of Casing [inch]

2.44

2.99

3.54

3.95

4.15

4.89

5.92

6.09

6.76

7.51

8.68

9.76

10.77

12.41

Max Differential Pressure [psi]

1.690

5000

4200

3000

2300

1800

1500

















2.125

6000

6000

5500

4400

3600

2600

1600

1500













2.500



6500

6200

6000

5500

4200

2600

2100

1600











2.750



7000

6800

6400

6000

5500

3700

3100

2300

1600









3.000





8000

7500

7000

6500

5000

4500

3400

2500

1500







3.375







8500

8000

7500

6500

6000

4500

3500

2300

1600





4.250











8500

7500

6500

5500

4500

3000

2100





5.375













8500

8000

7500

7000

6000

4000

3200

2200

6.500



















8000

6500

4500

3700

2700
